Kverneland 8576
Tedder | 3pt mounted Tedder
Productivity at the core
Heavy duty mounted tedder with compact transport dimensions
The advantages of this 3pt mounted Tedder
- Maintenance-free in season, except PTO
- Strong driveline including HexaLink finger clutch
- Sturdy design - V-shaped central unit
- Central adjustment for border spreading
- Largely dimensioned oscillation dampers
Description
Kverneland 8576, with 7.6m working width, is designed to perform perfectly in all crop conditions, with a minimum of non-productive maintenance required and with diminished transport dimensions. Featuring a heavy-duty fully closed headstock this machine will fit perfectly into the operation of professional farmers, looking for a strong, effective, and versatile tedder. This tedder is fitted with a high performance driveline combination. The complete driveline is maintenance-free, and offers highly reliable transfer of power, combined with extremely compact transport.
Highlights
- Fully maintenance-free in season, except PTO.
- Strong driveline, sturdy u-joints on the inside rotors and flexible HexaLink finger clutch on outside rotors.
- Compact transport and storage dimension – storage height is below 3.45m
- Strong and sturdy design with closed V-shaped central unit.
- Central adjustment for border spreading keeping the crop inside the field.
- Largely dimensioned oscillation dampers for excellent running characteristics.
- Optional headland kit for easy lifting on headlands.
Features
Features
Powered by a maintenance-free driveline and gearboxes, focus can be directed towards the essentials to maximise productivity. No time is wasted on time consuming greasing. Additionally the hinges are connected with strong maintenance-free roller bearings for extended longevity and stability of the connection points.
These machines offer very compact transport dimensions with their clever folding solution. A parking height below 4.0m is possible, due to the implementation of the new HexaLink finger clutch system in the joints of the two outer rotors. The remaining rotors are driven by maintenance-free double universal joints, for strong and efficient transfer of power.
To increase productivity, the Kverneland tedders can be equipped with a mechanical or an optional hydraulic border tedding device (hydraulic headland kit). A marker cleverly shows the position of the axle.
Kverneland's new generation of mounted tedders are designed to perform perfectly in all crop conditions, with a minimum of non-productive maintenance required. Featuring a heavy-duty fully closed headstock and a strong V-shaped central unit, the machine will fit perfectly into the operation of professional farmers, looking for a strong, effective, and versatile tedder.
- Kverneland oscillation dampers ensure excellent ground contour following and tedder flotation.
- The construction of the oscillation dampers results in a smooth and even distribution of the grass, thanks to the constant tine distance from the ground.
- Widely spaced mounting points - no risk of ‘hunting’.
- Excellent running characteristics.
- Low-positioned linkage on the headstock, for more effective damping action during transport.
- No risk of the tedder running under the tractor on downhill work, excellent tedding at all times through constant tine spacing to the ground.
Technical specifications
Technical specifications
Download brochure| Model ProLine | 8576 | |
|---|---|---|
| Working width (m/ft) | 7.60 / (24’11”) | |
| Number of rotors | 6 | |
| Number of tines/rotor | 7 | |
| Transport width (m/ft) | 2.96 / (9’9”) | |
| Transport length (m/ft) | 2.26 / (7’5”) | |
| Storage height (m/ft) | 3.46 / (11’4”) | |
| Capacity theor. (ha/h) | 6.1 |
Technical specifications
Technical specifications
Download brochureWorking Width |
Rotors/Tines |
Weight |
|
8555 |
5.50m |
4/7 |
620kg |
8568 |
6.80m |
6/6 |
900kg |
8576 |
7.60m |
6/7 |
980kg |
8590 |
8.90m |
8/6 |
1260kg |
85112 |
11.20m |
10/6 |
1600kg |
Product FAQ`s
The Kverneland 8576 three-point-mounted tedder has a 7.60 m working width and a heavy-duty driveline. Tractor suitability also depends on PTO compatibility, three-point linkage, lift capacity, tractor weight, stability, tyres, and ballast. Ask your Kverneland dealer to confirm the correct tractor match.
The Kverneland 8576 three-point-mounted tedder offers six rotors and a 7.60 m working width. Choose it when this capacity matches your acreage, tractor, mower output, field access, and weather windows. An eight-rotor tedder may provide greater output, but tractor requirements, transport dimensions, storage space, and following-machine capacity should also guide your decision.
The Kverneland 8576 three-point-mounted tedder has a 7.60 m working width and six rotors. Whether it matches your mower depends on mower width, swath placement, the number of swaths covered per pass, field layout, and required output. Compare the complete mowing, tedding, and raking pattern before selecting the tedder.
Set forward speed with the Kverneland 8576 three-point-mounted tedder according to crop volume, moisture, terrain, spreading quality, and forage cleanliness. The selected speed should maintain smooth, even crop distribution without unnecessary soil contamination or tine loading. Follow the current Kverneland operator manual for approved model-specific guidance.
The optional hydraulic headland kit for the Kverneland 8576 three-point-mounted tedder supports easier lifting at headlands. This assists manoeuvring when turning at field ends or working around obstacles. Confirm the required tractor hydraulics, equipment configuration, and local availability with your Kverneland dealer.
